CCIE Routing and Switching Training

Exam Description:The Cisco CCIE Routing and Switching Written Exam (400-101) version 5.0 is a two-hour test with 90−110 questions that will validate that professionals have the expertise to: configure, validate, and troubleshoot complex enterprise network infrastructure; and, understand how infrastructure components interoperate; and translate functional requirements into specific device configurations. The exam is closed book and no outside reference materials are allowed in our CCIE Routing and Switching Training Center



The following topics are general guidelines for the content likely to be included on the exam. However, other related topics may also appear on any specific delivery of the exam. In order to better reflect the contents of the exam and for clarity purposes, the guidelines below may change at any time without notice.




10% 1.0 Network Principles
1.1 Network theory
1.1.a Describe basic software architecture differences between IOS and IOS XE
1.1.a (i) Control plane and Forwarding plane
1.1.a (ii) Impact to troubleshooting and performances
1.1.a (iii) Excluding specific platform's architecture
1.1.b Identify Cisco express forwarding concepts
1.1.b (i) RIB, FIB, LFIB, Adjacency table
1.1.b (ii) Load balancing Hash
1.1.b (iii) Polarization concept and avoidance
1.1.c Explain general network challenges
1.1.c (i) Unicast flooding
1.1.c (ii) Out of order packets
1.1.c (iii) Asymmetric routing
1.1.c (iv) Impact of micro burst
1.1.d Explain IP operations
1.1.d (i) ICMP unreachable, redirect
1.1.d (ii) IPv4 options, IPv6 extension headers
1.1.d (iii) IPv4 and IPv6 fragmentation
1.1.d (iv) TTL
1.1.d (v) IP MTU
1.1.e Explain TCP operations
1.1.e (i) IPv4 and IPv6 PMTU
1.1.e (ii) MSS
1.1.e (iii) Latency
1.1.e (iv) Windowing
1.1.e (v) Bandwidth delay product
1.1.e (vi) Global synchronization
1.1.e (vii) Options
1.1.f Explain UDP operations
1.1.f (i) Starvation
1.1.f (ii) Latency
1.1.f (iii) RTP/RTCP concepts
1.2 Network implementation and operation
1.2.a Evaluate proposed changes to a network
1.2.a (i) Changes to routing protocol parameters
1.2.a (ii) Migrate parts of a network to IPv6
1.2.a (iii) Routing protocol migration
1.2.a (iv) Adding multicast support
1.2.a (v) Migrate spanning tree protocol
1.2.a (vi) Evaluate impact of new traffic on existing QoS design
1.3 Network troubleshooting
1.3.a Use IOS troubleshooting tools
1.3.a (i) debug, conditional debug
1.3.a (ii) ping, traceroute with extended options
1.3.a (iii) Embedded packet capture
1.3.a (iv) Performance monitor
1.3.b Apply troubleshooting methodologies
1.3.b (i) Diagnose the root cause of networking issue (analyze symptoms, identify and describe root cause)
1.3.b (ii) Design and implement valid solutions according to constraints
1.3.b (iii) Verify and monitor resolution
1.3.c Interpret packet capture
1.3.c (i) Using Wireshark trace analyzer
1.3.c (ii) Using IOS embedded packet capture
15% 2.0 Layer 2 Technologies
2.1 LAN switching technologies
2.1.a Implement and troubleshoot switch administration
2.1.a (i) Managing MAC address table
2.1.a (ii) errdisable recovery
2.1.a (iii) L2 MTU
2.1.b Implement and troubleshoot layer 2 protocols
2.1.b (i) CDP, LLDP
2.1.b (ii) UDLD
2013 Cisco Systems, Inc. This document is Cisco Public. Page 3
2.1.c Implement and troubleshoot VLAN
2.1.c (i) Access ports
2.1.c (ii) VLAN database
2.1.c (iii) Normal, extended VLAN, voice VLAN
2.1.d Implement and troubleshoot trunking
2.1.d (i) VTPv1, VTPv2, VTPv3, VTP pruning
2.1.d (ii) dot1Q
2.1.d (iii) Native VLAN
2.1.d (iv) Manual pruning
2.1.e Implement and troubleshoot EtherChannel
2.1.e (i) LACP, PAgP, manual
2.1.e (ii) Layer 2, layer 3
2.1.e (iii) Load-balancing
2.1.e (iv) Etherchannel misconfiguration guard
2.1.f Implement and troubleshoot spanning-tree
2.1.f (i) PVST+/RPVST+/MST
2.1.f (ii) Switch priority, port priority, path cost, STP timers
2.1.f (iii) port fast, BPDUguard, BPDUfilter
2.1.f (iv) loopguard, rootguard
2.1.g Implement and troubleshoot other LAN switching technologies
2.1.g (i) SPAN, RSPAN, ERSPAN
2.1.h Describe chassis virtualization and aggregation technologies
2.1.h (i) Multichassis
2.1.h (ii) VSS concepts
2.1.h (iii) Alternative to STP
2.1.h (iv) Stackwise
2.1.h (v) Excluding specific platform implementation
2.1.i Describe spanning-tree concepts
2.1.i (i) Compatibility between MST and RSTP
2.1.i (ii) STP dispute, STP bridge assurance
2.2 Layer 2 multicast
2.2.a Implement and troubleshoot IGMP
2.2.a (i) IGMPv1, IGMPv2, IGMPv3
2.2.a (ii) IGMP snooping
2.2.a (iii) IGMP querier
2.2.a (iv) IGMP filter
2.2.a (v) IGMP proxy
2.2.b Explain MLD
2.2.c Explain PIM snooping
2.3 Layer 2 WAN circuit technologies
2.3.a Implement and troubleshoot HDLC
2.3.b Implement and troubleshoot PPP
2.3.b (i) Authentication (PAP, CHAP)
2.3.b (ii) PPPoE
2.3.b (iii) MLPPP
2.3.c Describe WAN rate-based ethernet circuits
2.3.c (i) Metro and WAN Ethernet topologies
2.3.c (ii) Use of rate-limited WAN ethernet services
40% 3.0 Layer 3 Technologies
3.1 Addressing technologies
3.1.a Identify, implement and troubleshoot IPv4 addressing and subnetting
3.1.a (i) Address types, VLSM
3.1.a (ii) ARP
3.1.b Identify, implement and troubleshoot IPv6 addressing and subnetting
3.1.b (i) Unicast, multicast
3.1.b (ii) EUI-64
3.1.b (iii) ND, RS/RA
3.1.b (iv) Autoconfig/SLAAC, temporary addresses (RFC4941)
3.1.b (v) Global prefix configuration feature
3.1.b (vi) DHCP protocol operations
3.1.b (vii) SLAAC/DHCPv6 interaction
3.1.b (viii) Stateful, stateless DHCPv6
3.1.b (ix) DHCPv6 prefix delegation
3.2 Layer 3 multicast
3.2.a Troubleshoot reverse path forwarding
3.2.a (i) RPF failure
3.2.a (ii) RPF failure with tunnel interface
3.2.b Implement and troubleshoot IPv4 protocol independent multicast
3.2.b (i) PIM dense mode, sparse mode, sparse-dense mode
3.2.b (ii) Static RP, auto-RP, BSR
3.2.b (iii) BiDirectional PIM
3.2.b (iv) Source-specific multicast
3.2.b (v) Group to RP mapping
3.2.b (vi) Multicast boundary
3.2.c Implement and troubleshoot multicast source discovery protocol
3.2.c (i) Intra-domain MSDP (anycast RP)
3.2.c (ii) SA filter
3.2.d Describe IPv6 multicast
3.2.d (i) IPv6 multicast addresses
2013 Cisco Systems, Inc. This document is Cisco Public. Page 5
3.2.d (ii) PIMv6
3.3 Fundamental routing concepts
3.3.a Implement and troubleshoot static routing
3.3.b Implement and troubleshoot default routing
3.3.c Compare routing protocol types
3.3.c (i) Distance vector
3.3.c (ii) Link state
3.3.c (iii) Path vector
3.3.d Implement, optimize and troubleshoot administrative distance
3.3.e Implement and troubleshoot passive interface
3.3.f Implement and troubleshoot VRF lite
3.3.g Implement, optimize and troubleshoot filtering with any routing protocol
3.3.h Implement, optimize and troubleshoot redistribution between any routing protocol
3.3.i Implement, optimize and troubleshoot manual and auto summarization with any routing protocol
3.3.j Implement, optimize and troubleshoot policy-based routing
3.3.k Identify and troubleshoot sub-optimal routing
3.3.l Implement and troubleshoot bidirectional forwarding detection
3.3.m Implement and troubleshoot loop prevention mechanisms
3.3.m (i) Route tagging, filtering
3.3.m (ii) Split horizon
3.3.m (iii) Route poisoning
3.3.n Implement and troubleshoot routing protocol authentication
3.3.n (i) MD5
3.3.n (ii) Key-chain
3.3.n (iii) EIGRP HMAC SHA2-256bit
3.3.n (iv) OSPFv2 SHA1-196bit
3.3.n (v) OSPFv3 IPsec authentication
3.4 RIP (v2 and v6)
3.4.a Implement and troubleshoot RIPv2
3.4.b Describe RIPv6 (RIPng)
3.5 EIGRP (for IPv4 and IPv6)
3.5.a Describe packet types
3.5.a (i) Packet types (hello, query, update, and such)
3.5.a (ii) Route types (internal, external)
3.5.b Implement and troubleshoot neighbor relationship
3.5.b (i) Multicast, unicast EIGRP peering
3.5.b (ii) OTP point-to-point peering
3.5.b (iii) OTP route-reflector peering
3.5.b (iv) OTP multiple service providers scenario
3.5.c Implement and troubleshoot loop free path selection
3.5.c (i) RD, FD, FC, successor, feasible successor
3.5.c (ii) Classic metric
3.5.c (iii) Wide metric
3.5.d Implement and troubleshoot operations
3.5.d (i) General operations
3.5.d (ii) Topology table, update, query, active, passive
3.5.d (iii) Stuck in active
3.5.d (iv) Graceful shutdown
3.5.e Implement and troubleshoot EIGRP stub
3.5.e (i) Stub
3.5.e (ii) Leak-map
3.5.f Implement and troubleshoot load-balancing
3.5.f (i) equal-cost
3.5.f (ii) unequal-cost
3.5.f (iii) add-path
3.5.g Implement EIGRP (multi-address) named mode
3.5.g (i) Types of families
3.5.g (ii) IPv4 address-family
3.5.g (iii) IPv6 address-family
3.5.h Implement, troubleshoot and optimize EIGRP convergence and scalability
3.5.h (i) Describe fast convergence requirements
3.5.h (ii) Control query boundaries
3.5.h (iii) IP FRR/fast reroute (single hop)
3.5.8 (iv) Summary leak-map
3.5.h (v) Summary metric
3.6 OSPF (v2 and v3)
3.6.a Describe packet types
3.6.a (i) LSA yypes (1, 2, 3, 4, 5, 7, 9)
3.6.a (ii) Route types (N1, N2, E1, E2)
3.6.b Implement and troubleshoot neighbor relationship
3.6.c Implement and troubleshoot OSPFv3 address-family support
3.6.c (i) IPv4 address-family
3.6.c (ii) IPv6 address-family
3.6.d Implement and troubleshoot network types, area types and router types
3.6.d (i) Point-to-point, multipoint, broadcast, non-broadcast
3.6.d (ii) LSA types, area type: backbone, normal, transit, stub, NSSA, totally stub
3.6.d (iii) Internal router, ABR, ASBR
3.6.d (iv) Virtual link
3.6.e Implement and troubleshoot path preference
3.6.f Implement and troubleshoot operations
3.6.f (i) General operations
3.6.f (ii) Graceful shutdown
3.6.f (iii) GTSM (Generic TTL Security Mechanism)
3.6.g Implement, troubleshoot and optimize OSPF convergence and scalability
3.6.g (i) Metrics
3.6.g (ii) LSA throttling, SPF tuning, fast hello
3.6.g (iii) LSA propagation control (area types, ISPF)
3.6.g (iv) IP FRR/fast reroute (single hop)
3.6.g (v) LFA/loop-free alternative (multi hop)
3.6.g (vi) OSPFv3 prefix suppression
3.7 BGP
3.7.a Describe, implement and troubleshoot peer relationships
3.7.a (i) Peer-group, template
3.7.a (ii) Active, passive
3.7.a (iii) States, timers
3.7.a (iv) Dynamic neighbors
3.7.b Implement and troubleshoot IBGP and EBGP
3.7.b (i) EBGP, IBGP
3.7.b (ii) 4 bytes AS number
3.7.b (iii) Private AS
3.7.c Explain attributes and best-path selection
3.7.d Implement, optimize and troubleshoot routing policies
3.7.d (i) Attribute manipulation
3.7.d (ii) Conditional advertisement
3.7.d (iii) Outbound route filtering
3.7.d (iv) Communities, extended communities
3.7.d (v) Multi-homing
2013 Cisco Systems, Inc. This document is Cisco Public. Page 8
3.7.e Implement and troubleshoot scalability
3.7.e (i) Route-reflector, cluster
3.7.e (ii) Confederations
3.7.e (iii) Aggregation, AS set
3.7.f Implement and troubleshoot multiprotocol BGP
3.7.f (i) IPv4, IPv6, VPN address-family
3.7.g Implement and troubleshoot AS path manipulations
3.7.g (i) Local AS, allow AS in, remove private AS
3.7.g (ii) Prepend
3.7.g (iii) Regexp
3.7.h Implement and troubleshoot other features
3.7.h (i) Multipath
3.7.h (ii) BGP synchronization
3.7.h (iii) Soft reconfiguration, route refresh
3.7.i Describe BGP fast convergence features
3.7.i (i) Prefix independent convergence
3.7.i (ii) Add-path
3.7.i (iii) Next-hop address tracking
3.8 ISIS (for IPv4 and IPv6)
3.8.a Describe basic ISIS network
3.8.a (i) Single area, single topology
3.8.b Describe neighbor relationship
3.8.c Describe network types, levels and router types
3.8.c (i) NSAP addressing
3.8.c (ii) Point-to-point, broadcast
3.8.d Describe operations
3.8.e Describe optimization features
3.8.e (i) Metrics, wide metric

CCIE Routing and Switching Lab Exam Version 5.0

Exam Description:The CCIE® Routing and Switching Lab Exam version 5.0 is an eight-hour, hands-on exam which requires you to configure and troubleshoot a series of complex networks to given specifications. Knowledge of troubleshooting is an important skill and candidates are expected to diagnose and solve issues as part of the CCIE lab exam. You will not configure end-user systems, but are responsible for all devices residing in the network.



The following topics are general guidelines for the content likely to be included on the exam. However, other related topics may also appear on any specific delivery of the exam. In order to better reflect the contents of the exam and for clarity purposes, the guidelines below may change at any time without notice.

20% 1.0 Layer 2 Technologies
1.1 LAN switching technologies
1.1.a Implement and troubleshoot switch administration
1.1.a (i) Managing MAC address table
1.1.a (ii) errdisable recovery
1.1.a (iii) L2 MTU
1.1.b Implement and troubleshoot layer 2 protocols
1.1.b (i) CDP, LLDP
1.1.b (ii) UDLD
1.1.c Implement and troubleshoot VLAN
1.1.c (i) access ports
1.1.c (ii) VLAN database
1.1.c (iii) normal, extended VLAN, voice VLAN
1.1.d Implement and troubleshoot trunking
1.1.d (i) VTPv1, VTPv2, VTPv3, VTP pruning
1.1.d (ii) dot1Q
1.1.d (iii) Native VLAN
1.1.d (iv) Manual pruning
1.1.e Implement and troubleshoot etherchannel
1.1.e (i) LACP, PAgP, manual
1.1.e (ii) layer 2, layer 3
1.1.e (iii) load-balancing
1.1.e (iv) etherchannel misconfiguration guard
1.1.f Implement and troubleshoot spanning-tree
1.1.f (i) PVST+/RPVST+/MST
1.1.f (ii) switch priority, port priority, path cost, STP timers
1.1.f (iii) port fast, BPDUguard, BPDUfilter
1.1.f (iv) loopguard, rootguard
1.1.g Implement and troubleshoot other LAN switching technologies
2013 Cisco Systems, Inc. This document is Cisco Public. Page 2
1.1.g (i) SPAN, RSPAN, ERSPAN
1.2 Layer 2 Multicast
1.2.a Implement and troubleshoot IGMP
1.2.a (I) IGMPv1, IGMPv2, IGMPv3
1.2.a (ii) IGMP snooping
1.2.a (iii) IGMP querier
1.2.a (iv) IGMP filter
1.2.a (v) IGMP proxy
1.3 Layer 2 WAN circuit technologies
1.3.a Implement and troubleshoot HDLC
1.3.b Implement and troubleshoot PPP
1.3.b (i) authentication (PAP, CHAP)
1.3.b (ii) PPPoE
1.3.b (iii) MLPPP
1.4 Troubleshooting layer 2 technologies
1.4.a Use IOS troubleshooting tools
1.4.a (i) debug, conditional debug
1.4.a (ii) ping, traceroute with extended options
1.4.a (iii) Embedded packet capture
1.4.b Apply troubleshooting methodologies
1.4.b (i) Diagnose the root cause of networking issue (analyze symptoms, identify and describe root cause)
1.4.b (ii) Design and implement valid solutions according to constraints
1.4.b (iii) Verify and monitor resolution
1.4.c Interpret packet capture
1.4.c (i) Using wireshark trace analyzer
1.4.c (ii) Using IOS embedded packet capture
40% 2.0 Layer 3 Technologies
2.1 Addressing technologies
2.1.a Identify, implement and troubleshoot IPv4 addressing and sub-netting
2.1.a (i) Address types, VLSM
2.1.a (ii) ARP
2.1.b Identify, implement and troubleshoot IPv6 addressing and sub-netting
2.1.b (i) Unicast, multicast
2.1.b (ii) EUI-64
2.1.b (iii) ND, RS/RA
2.1.b (iv) Autoconfig/SLAAC temporary addresses (RFC4941)
2.1.b (v) Global prefix configuration feature
2.2 Layer 3 Multicast
2.2.a Troubleshoot reverse path forwarding
2.2.a (i) RPF failure
2.2.a(ii) RPF failure with tunnel interface
2.2.b Implement and troubleshoot IPv4 protocol independent multicast
2.2.b (i) PIM dense mode, sparse mode, sparse-dense mode
2.2.b (ii) Static RP, auto-RP, BSR
2.2.b (iii) Bidirectional PIM
2.2.b (iv) Source-specific multicast
2.2.b (v) Group to RP mapping
2.2.b (vi) Multicast boundary
2.2.c Implement and troubleshoot multicast source discovery protocol
2.2.c.(i) Intra-domain MSDP (anycast RP)
2.2.c.(ii) SA filter
2.3 Fundamental routing concepts
2.3.a Implement and troubleshoot static routing
2.3.b Implement and troubleshoot default routing
2.3.c Compare routing protocol types
2.3.c (i) distance vector
2.3.c (ii) link state
2.3.c (iii) path vector
2.3.d Implement, optimize and troubleshoot administrative distance
2.3.e Implement and troubleshoot passive interface
2.3.f Implement and troubleshoot VRF lite
2.3.g Implement, optimize and troubleshoot filtering with any routing protocol
2.3.h Implement, optimize and troubleshoot redistribution between any routing protocol
2.3.i Implement, optimize and troubleshoot manual and auto summarization with any routing protocol
2.3.j Implement, optimize and troubleshoot policy-based routing
2.3.k Identify and troubleshoot sub-optimal routing
2.3.l Implement and troubleshoot bidirectional forwarding detection
2.3.m Implement and troubleshoot loop prevention mechanisms
2.3.m (i) Route tagging, filtering
2.3.m (ii) Split horizon
2.3.m (iii) Route poisoning
2.3.n Implement and troubleshoot routing protocol authentication
2.3.n (i) MD5
2.3.n (ii) key-chain
2.3.n (iii) EIGRP HMAC SHA2-256bit
2.3.n (iv) OSPFv2 SHA1-196bit
2.3.n (v) OSPFv3 IPsec authentication
2.4 RIP v2
2.4.a Implement and troubleshoot RIPv2
2.5 EIGRP (for IPv4 and IPv6)
2.5.a Describe packet types
2.5.a (i) Packet types (hello, query, update, and such)
2.5.a (ii) Route types (internal, external)
2.5.b Implement and troubleshoot neighbor relationship
2013 Cisco Systems, Inc. This document is Cisco Public. Page 4
2.5.b (i) Multicast, unicast EIGRP peering
2.5.c Implement and Troubleshoot Loop free path selection
2.5.c (i) RD, FD, FC, successor, feasible successor
2.5.c (ii) Classic metric
2.5.c (iii) Wide metric
2.5.d Implement and troubleshoot operations
2.5.d (i) General operations
2.5.d (ii) Topology table, update, query, active, passive
2.5.d (iii) Stuck in active
2.5.d (iv) Graceful shutdown
2.5.e Implement and troubleshoot EIGRP stub
2.5.e (i) stub
2.5.e (ii) leak-map
2.5.f Implement and troubleshoot load-balancing
2.5.f (i) equal-cost
2.5.f (ii) unequal-cost
2.5.f (iii) add-path
2.5.g Implement EIGRP (multi-address) named mode
2.5.g (i) Types of families
2.5.g (ii) IPv4 address-family
2.5.g (iii) IPv6 address-family
2.5.h Implement, troubleshoot and optimize EIGRP convergence and scalability
2.5.h (i) Describe fast convergence requirements
2.5.h (ii) Control query boundaries
2.5.h (iii) IP FRR/fast reroute (single hop)
2.5.h (iv) Summary leak-map
2.5.h (v) Summary metric
2.6 OSPF (v2 and v3)
2.6.a Describe packet types
2.6.a (i) LSA types (1, 2, 3, 4, 5, 7, 9)
2.6.a (ii) Route types (N1, N2, E1, E2)
2.6.b Implement and troubleshoot neighbor relationship
2.6.c Implement and troubleshoot OSPFv3 address-family support
2.6.c (i) IPv4 address-family
2.6.c (ii) IPv6 address-family
2.6.d Implement and troubleshoot network types, area types and router types
2.6.d (i) Point-to-point, multipoint, broadcast, non-broadcast
2.6.d (ii) LSA types, area type: backbone, normal, transit, stub, NSSA, totally stub
2.6.d (iii) Internal router, ABR, ASBR
2.6.d (iv) Virtual link
2.6.e Implement and troubleshoot path preference
2.6.f Implement and troubleshoot operations
2.6.f (i) General operations
2.6.f (ii) Graceful shutdown
2.6.f (iii) GTSM (generic TTL security mechanism)
2.6.g Implement, troubleshoot and optimize OSPF convergence and scalability
2.6.g (i) Metrics
2.6.g (ii) LSA throttling, SPF tuning, fast hello
2.6.g (iii) LSA propagation control (area types, ISPF)
2.6.g (iv) IP FR/fast reroute (single hop)
2.6.g (v) LFA/loop-free alternative (multi hop)
2.6.g (vi) OSPFv3 prefix suppression
2.7 BGP
2.7.a Describe, implement and troubleshoot peer relationships
2.7.a (i) Peer-group, template
2.7.a (ii) Active, passive
2.7.a (iii) States, timers
2.7.a (iv) Dynamic neighbors
2.7.b Implement and troubleshoot IBGP and EBGP
2.7.b (i) EBGP, IBGP
2.7.b (ii) 4 bytes AS number
2.7.b (iii) Private AS
2.7.c Explain attributes and best-path selection
2.7.d Implement, optimize and troubleshoot routing policies
2.7.d (i) Attribute manipulation
2.7.d (ii) Conditional advertisement
2.7.d (iii) Outbound route filtering
2.7.d (iv) Communities, extended communities
2.7.d (v) Multi-homing
2.7.e Implement and troubleshoot scalability
2.7.e (i) Route-reflector, cluster
2.7.e (ii) Confederations
2.7.e (iii) Aggregation, AS set
2.7.f Implement and troubleshoot multi-protocol BGP
2.7.f (i) IPv4, IPv6, VPN address-family
2.7.g Implement and troubleshoot AS path manipulations
2.7.g (i) Local AS, allow AS in, remove private AS
2.7.g (ii) Prepend
2.7.g (iii) Regexp
2.7.h Implement and Troubleshoot Other Features
2.7.h (i) Multipath
2.7.h (ii) BGP synchronization
2.7.h (iii) Soft reconfiguration, route refresh
2.8 Troubleshooting layer 3 technologies
2.8.a Use IOS troubleshooting tools
2.8.a (i) debug, conditional debug
2.8.a (ii) ping, traceroute with extended options
2.8.a (iii) Embedded packet capture
2.8.b Apply troubleshooting methodologies
2.8.b (i) Diagnose the root cause of networking issue (analyze symptoms, identify and describe root cause)
2.8.b (ii) Design and implement valid solutions according to constraints
2.8.b (iii) Verify and monitor resolution
2.8.c Interpret packet capture
2.8.c (i) Using wireshark trace analyzer
2.8.c (ii) Using IOS embedded packet capture
20% 3.0 VPN Technologies
3.1 Tunneling
3.1.a Implement and troubleshoot MPLS operations
3.1.a (i) Label stack, LSR, LSP
3.1.a (ii) LDP
3.1.a (iii) MPLS ping, MPLS traceroute
3.1.b Implement and troubleshoot basic MPLS L3VPN
3.1.b (i) L3VPN, CE, PE, P
3.1.b (ii) Extranet (route leaking)
3.1.c Implement and troubleshoot encapsulation
3.1.c (i) GRE
3.1.c (ii) Dynamic GRE
3.1.d Implement and troubleshoot DMVPN (single hub)
3.1.d (i) NHRP
3.1.d (ii) DMVPN with IPsec using preshared key
3.1.d (iii) QoS profile
3.1.d (iv) Pre-classify
3.2 Encryption
3.2.a Implement and troubleshoot IPsec with preshared key
3.2.a (i) IPv4 site to IPv4 site
3.2.a (ii) IPv6 in IPv4 tunnels
3.2.a (iii) Virtual tunneling interface (VTI)
3.3 Troubleshooting VPN technologies
3.3.a Use IOS troubleshooting tools
3.3.a (i) debug, conditional debug
3.3.a (ii) ping, traceroute with extended options
3.3.a (iii) Embedded packet capture
3.3.b Apply troubleshooting methodologies
3.3.b (i) Diagnose the root cause of networking issue (analyze symptoms, identify and describe root cause)
3.3.b (ii) Design and implement valid solutions according to constraints
3.3.b (iii) Verify and monitor resolution
3.3.c Interpret packet capture
3.3.c (i) Using wireshark trace analyzer
3.3.c (ii) Using IOS embedded packet capture
5% 4.0 Infrastructure Security
4.1 Device security
4.1.a Implement and troubleshoot IOS AAA using local database
4.1.b Implement and troubleshoot device access control
4.1.b (i) Lines (VTY, AUX, console)
4.1.b (ii) SNMP
4.1.b (iii) Management plane protection
4.1.b (iv) Password encryption
4.1.c Implement and troubleshoot control plane policing
4.2 Network security
4.2.a Implement and troubleshoot switch security features
4.2.a (i) VACL, PACL
4.2.a (ii) Stormcontrol
4.2.a (iii) DHCP snooping
4.2.a (iv) IP source-guard
4.2.a (v) Dynamic ARP inspection
4.2.a (vi) Port-security
4.2.a (vii) Private VLAN
4.2.b Implement and troubleshoot router security features
4.2.b (i) IPv4 access control lists (standard, extended, time-based)
4.2.b (ii) IPv6 traffic filter
4.2.b (iii) Unicast reverse path forwarding
4.2.c Implement and troubleshoot IPv6 first hop security
4.2.c (i) RA guard
4.2.c (ii) DHCP guard
4.2.c (iii) Binding table
4.2.c (iv) Device tracking
4.2.c (v) ND inspection/snooping
4.2.c (vi) Source guard
4.2.c (vii) PACL
4.3 Troubleshooting infrastructure security
4.3.a Use IOS troubleshooting tools
4.3.a (i) debug, conditional debug
4.3.a (ii) ping, traceroute with extended options
4.3.a (iii) Embedded packet capture
4.3.b Apply troubleshooting methodologies
4.3.b (i) Diagnose the root cause of networking issue (analyze symptoms, identify and describe root cause)
4.3.b (ii) Design and implement valid solutions according to constraints
4.3.b (iii) Verify and monitor resolution
4.3.c Interpret packet capture
4.3.c (i) Using wireshark trace analyzer
4.3.c (ii) Using IOS embedded packet capture

About iNet Infotech

Contact

Copyright © 2008 i-Net Infotech. All rights reserved.
